ST STM32F207 series User Manual

RM0033 Rev 9 95/1381
RM0033 Reset and clock control (RCC)
137
5.3 RCC registers
The RCC registers can be accessed by bytes (8 bits), half-words (16 bits) or words (32 bits).
Refer to Section 1.2 on page 46 for a list of abbreviations used in register descriptions.
5.3.1 RCC clock control register (RCC_CR)
Address offset: 0x00
Reset value: 0x0000 XX83 where X is undefined.
Access: no wait state, word, half-word and byte access
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
PLLI2S
RDY
PLLI2
SON
PLLRDY
PLLO
N
Reserved
CSS
ON
HSE
BYP
HSE
RDY
HSE
ON
r
rw
r
rw rw rw r rw
1514131211109 87654321 0
HSICAL[7:0] HSITRIM[4:0]
Res.
HSI
RDY
HSIO
N
rrrrrrr rrwrwrwrwrw rrw
Bits 31:28 Reserved, always read as 0.
Bit 27 PLLI2SRDY: PLLI2S clock ready flag
Set by hardware to indicate that the PLLI2S is locked.
0: PLLI2S unlocked
1: PLLI2S locked
Bit 26 PLLI2SON: PLLI2S enable
Set and cleared by software to enable PLLI2S.
Cleared by hardware when entering Stop or Standby mode.
0: PLLI2S OFF
1: PLLI2S ON
Bit 25 PLLRDY: Main PLL (PLL) clock ready flag
Set by hardware to indicate that PLL is locked.
0: PLL unlocked
1: PLL locked
Bit 24 PLLON: Main PLL (PLL) enable
Set and cleared by software to enable PLL.
Cleared by hardware when entering Stop or Standby mode. This bit cannot be reset if PLL
clock is used as the system clock.
0: PLL OFF
1: PLL ON
Bits 23:20 Reserved, always read as 0.
Bit 19 CSSON: Clock security system enable
Set and cleared by software to enable the clock security system. When CSSON is set, the
clock detector is enabled by hardware when the HSE oscillator is ready, and disabled by
hardware if an oscillator failure is detected.
0: Clock security system OFF (Clock detector OFF)
1: Clock security system ON (Clock detector ON if HSE oscillator is stable, OFF if not)
