32.18 DBG register map
The following table summarizes the Debug registers.
Table 223. DBG register map and reset values
Addr. Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0xE004
2000
DBGMCU
_IDCODE
REV_ID
Reserved
DEV_ID
Reset value
(1)
XXXXXXXXXXXXXXXX XXXXXXXXXXXX
0xE004
2004
DBGMCU_CR
Reserved
DBG_TIM7_STOP DBG_TIM6_STOP DBG_TIM5_STOP DBG_TIM8_STOP
DBG_I2C2_SMBUS_TIMEOUT
Reserved
TRACE_
MODE
[1:0]
TRACE_
Reserved
DBG_STANDBY
DBG_STOP
DBG_SLEEP
Reset value 00000 000 000
0xE004
2008
DBGMCU_
APB1_FZ
Reserved
DBG_CAN2_STOP DBG_CAN1_STOP
Reserved
DBG_I2C3_SMBUS_TIMEOUT DBG_I2C2_SMBUS_TIMEOUT DBG_I2C1_SMBUS_TIMEOUT
Reserved
DBG_IWDG_STOP
DBG_WWDG_STOP
Reserved
DBG_RTC_STOP
DBG_TIM14_STOP DBG_TIM13_STOP DBG_TIM12_STOP
DBG_TIM7_STOP DBG_TIM6_STOP DBG_TIM5_STOP DBG_TIM4_STOP DBG_TIM3_STOP DBG_TIM2_STOP
Reset value 000000 00 0000000000
0xE004
200C
DBGMCU_
APB2_FZ
Reserved
DBG_TIM11_STOP
DBG_TIM10_STOP
DBG_TIM9_STOP
Reserved
DBG_TIM8_STOP DBG_TIM1_STOP
Reset value 0 0 0 0 0
1. The reset value is product dependent. For more information, refer to Section 32.6.1: MCU device ID code.
