Hash processor (HASH) RM0033
564/1381 RM0033 Rev 9
21.4.4 HASH digest registers (HASH_HR0..4)
Address offset: 0x0C to 0x1C
Reset value: 0x0000 0000
These registers contain the message digest result named as:
1. H0, H1, H2, H3 and H4, respectively, in the SHA1 algorithm description
2. A, B, C and D, respectively, in the MD5 algorithm description
Note that in this case, the HASH_H4 is not used, and is read as zero.
3. H0 to H6, respectively, in the SHA224 algorithm description,
4. H0 to H7, respectively, in the SHA256 algorithm description,
If a read access to one of these registers occurs while the HASH core is calculating an
intermediate digest or a final message digest (that is when the DCAL bit has been written to
1), then the read is stalled until the completion of the HASH calculation.
HASH_HR0
Address offset: 0x0C
HASH_HR1
Address offset: 0x10
HASH_HR2
Address offset: 0x14
HASH_HR3
Address offset: 0x18
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
H0
rrrrrrrrrrrrrrrr
1514131211109876543210
H0
rrrrrrrrrrrrrrrr
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
H1
rrrrrrrrrrrrrrrr
1514131211109876543210
H1
rrrrrrrrrrrrrrrr
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
H2
rrrrrrrrrrrrrrrr
1514131211109876543210
H2
rrrrrrrrrrrrrrrr
