22.6.2 RTC date register (RTC_DR)
The RTC_DR is the calendar date shadow register. This register must be written in
initialization mode only. Refer to
Calendar initialization and configuration on page 575 and
Reading the calendar on page 576.
Address offset: 0x04
Backup domain reset value: 0x0000 2101
System reset: 0x0000 2101 before the RSF flag is set, then the correct value is available.
Note: This register is write protected. The write access procedure is described in RTC register
write protection on page 574.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
YT[3:0] YU[3:0]
rw rw rw rw rw rw rw rw
1514131211109876543210
WDU[2:0] MT MU[3:0]
Reserved
DT[1:0] DU[3:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31-24 Reserved
Bits 23:20 YT[3:0]: Year tens in BCD format
Bits 19:16 YU[3:0]: Year units in BCD format
Bits 15:13 WDU[2:0]: Week day units
000: forbidden
001: Monday
...
111: Sunday
Bit 12 MT: Month tens in BCD format
Bits 11:8 MU: Month units in BCD format
Bits 7:6 Reserved, must be kept at reset value.
Bits 5:4 DT[1:0]: Date tens in BCD format
Bits 3:0 DU[3:0]: Date units in BCD format
