RM0033 Rev 9 81/1381
RM0033 Power control (PWR)
83
4.4.2 PWR power control/status register (PWR_CSR)
Address offset: 0x04
Reset value: 0x0000 0000 (not reset by wakeup from Standby mode)
Additional APB cycles are needed to read this register versus a standard APB read.
Bit 3 CSBF: Clear standby flag
This bit is always read as 0.
0: No effect
1: Clear the SBF Standby Flag (write).
Bit 2 CWUF: Clear wakeup flag
This bit is always read as 0.
0: No effect
1: Clear the WUF Wakeup Flag after 2 System clock cycles
Bit 1 PDDS: Power down deepsleep
This bit is set and cleared by software. It works together with the LPDS bit.
0: Enter Stop mode when the CPU enters deepsleep. The regulator status depends on the
LPDS bit.
1: Enter Standby mode when the CPU enters deepsleep.
Bit 0 LPDS: Low-power deep sleep
This bit is set and cleared by software. It works together with the PDDS bit.
0: Voltage regulator on during Stop mode
1: Voltage regulator in low-power mode during Stop mode
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
Res.
1514131211109876543210
Reserved
Res.
BRE EWUP
Reserved
Res.
BRR PVDO SBF WUF
rw rw r r r r
Bits 31:10 Reserved, always read as 0.
Bit 9 BRE: Backup regulator enable
When set, the Backup regulator (used to maintain backup SRAM content in Standby and V
BAT
modes) is enabled. If BRE is reset, the backup regulator is switched off. The backup SRAM
can still be used but its content will be lost in the Standby and V
BAT
modes. Once set, the
application must wait that the Backup Regulator Ready flag (BRR) is set to indicate that the
data written into the RAM will be maintained in the Standby and V
BAT
modes.
0: Backup regulator disabled
1: Backup regulator enabled
Note: This bit is not reset when the device wakes up from Standby mode, by a system reset,
or by a power reset.
