Random number generator (RNG) RM0033
548/1381 RM0033 Rev 9
20.4.4 RNG register map
Table 7 6 gives the RNG register map and reset values.
Table 76. RNG register map and reset map
Offset
Register
name
reset value
Register size
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
RNG_CR
0x0000000
Reserved
IE
RNGEN
Reserved
0x04
RNG_SR
0x0000000
Reserved
SEIS
CEIS
Reserved
SECS
CECS
DRDY
0x08
RNG_DR
0x0000000
RNDATA[31:0]
