1 Documentation conventions
1.1 General information
The STM32F205xx, STM32F207xx, STM32F215xx and STM32F217xx devices have an
Arm
®(a)
Cortex
®
-M3 core.
1.2 List of abbreviations for registers
The following abbreviations are used in register descriptions:
1.3 Glossary
• Word: data of 32-bit length.
• Half-word: data of 16-bit length.
• Byte: data of 8-bit length.
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
read/write (rw) Software can read and write to these bits.
read-only (r) Software can only read these bits.
write-only (w) Software can only write to this bit. Reading the bit returns the reset
value.
read/clear (rc_w1) Software can read as well as clear this bit by writing 1. Writing ‘0’ has
no effect on the bit value.
read/clear (rc_w0) Software can read as well as clear this bit by writing 0. Writing ‘1’ has
no effect on the bit value.
read/clear by read
(rc_r)
Software can read this bit. Reading this bit automatically clears it to ‘0’.
Writing ‘0’ has no effect on the bit value.
read/set (rs) Software can read as well as set this bit. Writing ‘0’ has no effect on the
bit value.
read-only write
trigger (rt_w)
Software can read this bit. Writing ‘0’ or ‘1’ triggers an event but has no
effect on the bit value.
toggle (t) Software can only toggle this bit by writing ‘1’. Writing ‘0’ has no effect.
Reserved (Res.) Reserved bit, must be kept at reset value.
