RM0033 Window watchdog (WWDG)
507
18.6.4 WWDG register map
The following table gives the WWDG register map and reset values.
Refer to Section 3.3: Memory map for the register boundary addresses.
Table 72. WWDG register map and reset values
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
WWDG_CR
Reserved
WDGA
T[6:0]
Reset value 01111111
0x04
WWDG_CFR
Reserved
EWI
WDGTB1 WDGTB0
W[6:0]
Reset value 0001111111
0x08
WWDG_SR
Reserved
EWIF
Reset value 0
