Page #149 background imageLoading...
Page #149 background image
RM0033 Rev 9 149/1381
RM0033 General-purpose I/Os (GPIO)
158
6.3.15 Selection of RTC_AF1 and RTC_AF2 alternate functions
The STM32F4xx feature two GPIO pins RTC_AF1 and RTC_AF2 that can be used for the
detection of a tamper or time stamp event, or AFO_ALARM, or AFO_CALIB RTC outputs.
The RTC_AF1 (PC13) can be used for the following purposes:
RTC AFO_ALARM output: this output can be RTC Alarm A, RTC Alarm B or RTC Wakeup
depending on the OSEL[1:0] bits in the RTC_CR register
RTC AFO_CALIB output: this feature is enabled by setting the COE[23] in the RTC_CR
register
RTC AFI_TAMPER1: tamper event detection
RTC AFI_TIMESTAMP: time stamp event detection
The RTC_AF2 (PI8) can be used for the following purposes:
RTC AFI_TAMPER1: tamper event detection
RTC AFI_TAMPER2: tamper event detection
RTC AFI_TIMESTAMP: time stamp event detection
The selection of the corresponding pin is performed through the RTC_TAFCR register as
follows:
TAMP1INSEL is used to select which pin is used as the AFI_TAMPER1 tamper input
TSINSEL is used to select which pin is used as the AFI_TIMESTAMP time stamp input
ALARMOUTTYPE is used to select whether the RTC AFO_ALARM is output in push-
pull or open-drain mode
The output mechanism follows the priority order listed in Table 16 and Table 17.
Table 16. RTC_AF1 pin
(1)
Pin
configuration
and function
AFO_ALARM
enabled
AFO_CALIB
enabled
Tamper
enabled
Time
stamp
enabled
TAMP1INSEL
TAMPER1
pin selection
TSINSEL
TIMESTAMP
pin
selection
ALARMOUTTYPE
AFO_ALARM
configuration
Alarm out
output OD
1Dont care
Don’t
care
Don’t
care
Don’t care Don’t care 0
Alarm out
output PP
1Dont care
Don’t
care
Don’t
care
Don’t care Don’t care 1
Calibration
out output PP
01
Don’t
care
Don’t
care
Don’t care Don’t care Don’t care
TAMPER1
input floating
0 0 1 0 0 Don’t care Don’t care
TIMESTAMP
and
TAMPER1
input floating
0 0 1 1 0 0 Don’t care
TIMESTAMP
input floating
0 0 0 1 Don’t care 0 Don’t care
Standard
GPIO
0 0 0 0 Don’t care Don’t care Don’t care
1. OD: open drain; PP: push-pull.
