ST STM32F207 series User Manual

RM0033 Rev 9 211/1381
RM0033 DMA controller (DMA)
211
Refer to Section 2.3: Memory map for the register boundary addresses.
0x00AC
DMA_S6M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x00B0
DMA_S6M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x00B4
DMA_S6FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
0x00B8
DMA_S7CR
Reserved
CHSEL[2:0]
MBURST[1:0]
PBURST[1:0]
Reserved
CT
DBM
PL[1:0]
PINCOS
MSIZE[1:0]
PSIZE[1:0]
MINC
PINC
CIRC
DIR[1:0]
PFCTRL
TCIE HTIE
TEIE
DMEIE
EN
Reset value 0000000 0000
-
000000000000000
0x00BC
DMA_S7NDTR
Reserved
NDT[15:.]
Reset value 0000000000000000
0x00C0
DMA_S7PAR PA[31:0]
Reset value 00000000000000000000000000000000
0x00C4
DMA_S7M0AR M0A[31:0]
Reset value 00000000000000000000000000000000
0x00C8
DMA_S7M1AR M1A[31:0]
Reset value 00000000000000000000000000000000
0x00CC
DMA_S7FCR
Reserved
FEIE
Reserved
FS[2:0]
DMDIS
FTH
[1:0]
Reset value 0 100001
Table 31. DMA register map and reset values (continued)
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
