General-purpose timers (TIM2 to TIM5) RM0033
436/1381 RM0033 Rev 9
Refer to Section 3.3: Memory map for the register boundary addresses.
0x2C
TIMx_ARR
ARR[31:16]
(TIM2 and TIM5 only, reserved on the other timers)
ARR[15:0]
Reset value 11111111111111111 1 1 1 111111111111
0x30
Reserved
0x34
TIMx_CCR1
CCR1[31:16]
(TIM2 and TIM5 only, reserved on the other timers)
CCR1[15:0]
Reset value 00000000000000000 0 0 0 000000000000
0x38
TIMx_CCR2
CCR2[31:16]
(TIM2 and TIM5 only, reserved on the other timers)
CCR2[15:0]
Reset value 00000000000000000 0 0 0 000000000000
0x3C
TIMx_CCR3
CCR3[31:16]
(TIM2 and TIM5 only, reserved on the other timers)
CCR3[15:0]
Reset value 00000000000000000 0 0 0 000000000000
0x40
TIMx_CCR4
CCR4[31:16]
(TIM2 and TIM5 only, reserved on the other timers)
CCR4[15:0]
Reset value 00000000000000000 0 0 0 000000000000
0x44
Reserved
0x48
TIMx_DCR
Reserved
DBL[4:0]
Reserved
DBA[4:0]
Reset value 00000 00000
0x4C
TIMx_DMAR
Reserved
DMAB[15:0]
Reset value 0000000000000000
0x50
TIM2_OR
Reserved Reserved
ITR1_
RMP
Reserved
Reset value 00
0x50
TIM5_OR
Reserved Reserved
IT4_
RMP
Reserved
Reset value 00
Table 62. TIM2 to TIM5 register map and reset values (continued)
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
