ST STM32F207 series User Manual

Controller area network (bxCAN) RM0033
836/1381 RM0033 Rev 9
0x1C4
CAN_RDT1R TIME[15:0] FMI[7:0]
Reserved
DLC[3:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxx xxxx
0x1C8
CAN_RDL1R DATA3[7:0] DATA2[7:0] DATA1[7:0] DATA0[7:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1CC
CAN_RDH1R DATA7[7:0] DATA6[7:0] DATA5[7:0] DATA4[7:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x1D0-
0x1FF
Reserved
0x200
CAN_FMR
Reserved
CAN2SB[5:0]
Reserved
FINIT
Reset value 001110 1
0x204
CAN_FM1R
Reserved
FBM[27:0]
Reset value 0000000000000000000000000000
0x208
Reserved
0x20C
CAN_FS1R
Reserved
FSC[27:0]
Reset value 0000000000000000000000000000
0x210
Reserved
0x214
CAN_FFA1R
Reserved
FFA[27:0]
Reset value 0000000000000000000000000000
0x218
Reserved
0x21C
CAN_FA1R
Reserved
FACT[27:0]
Reset value 0000000000000000000000000000
0x220
Reserved
0x224-
0x23F
Reserved
0x240
CAN_F0R1 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x244
CAN_F0R2 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
0x248
CAN_F1R1 FB[31:0]
Reset value xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
Table 137. bxCAN register map and reset values (continued)
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
