APPENDIX 9
MHL360 E 9.3
Fuse number
Tripping cur-
rent intensity
Terminal de-
signation
Function
F 67
3 A
Terminal 15
Diagnostic plug, motor control unit
F 68 30 A Terminal 15 Diesel engine SCR system
F 69
15 A
Terminal 15
Control, cab floor, CR0303, VBBo03
F 70
15 A
Terminal 15
Reserve
F 71
10 A
Terminal 15
Control, cab floor, CR0303, VBBo17
F 72
10 A
Terminal 15
Control, cab floor, CR0303, VBBo12
F 73 15 A Terminal 15 Reserve
F 74
15 A
Terminal 15
NOx Sensor
F 75
10 A
Terminal 15
Control, cab floor, CR0303, VBBo13
F 76
10 A
Terminal 15
Control, cab floor, CR0303, VBBs
F 77
10 A
Terminal 15
Control, cab floor, CR0303, VBBo14
F 78 10 A Terminal 15 Diesel engine Y20 for exhaust gas recirculation
F 79
15 A
Terminal 15
Control, cab floor, CR0303, VBBo01
F 80
15 A
Terminal 15
CR0032 central electrical system, VBBr option
F 81
15 A
Terminal 15
Fuel filter heating
F 82
3 A
Terminal 15
CR0032 central electrical system, VBB15 option
F 83 15 A Terminal 15 CR0032 central electrical system, VBBo option
F 84
2 A
Terminal 15
Charge voltage D+
F 85
2 A
Terminal 15
Four-way control lever steering, steering valve PVG32
F 86
20 A
Terminal 15
CR2016 undercarriage, VBBo2
F 87
20 A
Terminal 15
CR2016 undercarriage, VBBo1
F 88 1 A Terminal 15 Diesel engine, M11 burner air pump, D9 glow plug control
unit
F 89
5 A
Terminal 15
CR2012 central electrical system, option
F 90
2 A
Terminal 15
CR0032 central electrical system, VBBs option
F 91
15 A
Terminal 15
Cab protection ventilation (special equipment)
F 92 2 A Terminal 15 Tank sensor
CR0032
Option control
CR0232
Main control
CR0303
Cab control
CR2012
I/O expansion
VBB...
Power supply for control modules
The following fuses are located in the distribution box in the engine compartment
Fuse
Function
F1.1-Mega 125 A
Terminal 30
F1.2-Mega 125 A
Power relay K2 terminal 15
F1.3-Mega 1 A Reserve
F1.4-Mega 150 A
Generator B+
F1.5-Midi 60 A
Burner, air pump
