Terex MHL360 E - Page 316

9 APPENDIX
9.2 MHL360 E
Fuse number
Tripping cur-
rent intensity
Terminal de-
signation
Function
F 31
15 A
Terminal 15
CR0232, VBB1
F 32 10 A Terminal 15 Driver's seat
F 33
15 A
Terminal 15
CR0232, VBB4
F 34
5 A
Terminal 15
CR0232 sensors, auto-idling system, driving, parking
brake, maintenance ladder, work zone extension, dipper-
stick, overload warning system, float switch, angle trans-
mitter
F 35
1 A
Terminal 15
CR0032 and CAN4 programming interface
F 36
15 A
Terminal 15
CR0232, VBB3
F 37
5 A
Terminal 15
CR0232 sensors, Start/Stop button, emergency control,
hydraulic oil return filter, hydraulic oil temperature, hydrau-
lic oil level,
F 38
2 A
Terminal 15
CR0232, VBBRel
F 39
15 A
Terminal 15
CR0232, VBB2
F 40
15 A
Terminal 15
Right headlight
F 41
2 A
Terminal 15
Throttle valve
F 42 5 A Terminal 15 CR0232 sensors, tool filter: rotate gripper, tool filter: grip-
per open/closed, filter: water/charge air cooler, filter: hy-
draulic oil cooler (all optional)
F 43
15 A
Terminal 15
Working floodlights, boom
F 44
15 A
Terminal 15
Working headlamps, dipperstick
F 45 20 A Terminal 15 Air conditioning system: condenser
F 46
10 A
Terminal 15
Air conditioning system: condenser
F 47
10 A
Terminal 15
Air conditioning system: condenser
F 48
2 A
Terminal 15
Air conditioning system: control unit
F 49
5 A
Terminal 15
Voltage converter
F 50 7.5 A Terminal 15 Rexroth / Linde load limit sensing control
F 51
1 A
Terminal 15
Rear view camera
F 52
1 A
Terminal 15
Multifunction button
F 53
5 A
Terminal 15
Four-way control lever
F 54
7.5 A
Terminal 15
Air conditioning system: magnetic coupling
F 55 5 A Terminal 15 radio
F 56
1 A
Terminal 15
Operator panel, cab
F 57
2 A
Terminal 15
Alternator terminal 15
F 58
3 A
Terminal 15
Fuchs Quick Connect sensors (special equipment)
F 59
10 A
Terminal 15
Air conditioning system: condenser
F 60
7.5 A
Terminal 15
Main window wiper, lower window wiper (optional)
F 61
15 A
Terminal 15
Emergency control
F 62
15 A
Terminal 15
Air conditioning system: fans
F 63
10 A
Terminal 15
Compressor, reversing fan mode
F 64
10 A
Terminal 15
Control, cab floor, CR0303, VBBo16
F 65
10 A
Terminal 15
Control, cab floor, CR0303, VBBo15
F 66
15 A
Terminal 15
Control, cab floor, CR0303, VBBo02
