Terex MHL360 E - Arrangement of Fuses

APPENDIX 9
MHL360 E 9.1
9 Appendix
9.1 Arrangement of fuses
j WARNING
Danger of injury due to malfunctions
• Use only original fuses.
• Electrical fuses must never be bypassed or repaired.
In an emergency: Switch off machine, administer first aid, seek treatment from a doctor
The table below shows the fuses and relays in the central electrical system:
Fuse number
Tripping cur-
rent intensity
Terminal de-
signation
Function
F 1
80 A
Terminal 30
Master fuse terminal 30
F 2
80 A
Terminal 30
Master fuse terminal 30
F 3
80 A
Terminal 15
Master fuse terminal 15
F 4
80 A
Terminal 15
Master fuse terminal 15
F 5 3 A Terminal 30 Interior light
F 6
7.5 A
Terminal 30
Side lights
F 7
5 A
Terminal 30
Multifunction display
F 8
15 A
Terminal 30
Reserve
F 9
5 A
Terminal 30
Voltage converter
F 10 7.5 A Terminal 30 Radio / CD
F 11
15 A
Terminal 30
Reserve
F 12
7.5 A
Terminal 30
24 V socket
F 13
15 A
Terminal 30
Supplementary heating
F 14
10 A
Terminal 30
Cigarette lighter
F 15 5 A Terminal 30 Supplementary heating
F 16
20 A
Terminal 30
Refueling pump
F 17
15 A
Terminal 30
Reserve
F 18
7.5 A
Terminal 30
CR0232, VBBS, VBB15, ignition lock
F 19
15 A
Terminal 30
CR0232, VBBo
F 20 25 A Terminal 30 Glow plug control unit
F 21
15 A
Terminal 30
Reserve
F 22
2 A
Terminal 30
Alternator terminal 30
F 23
15 A
Terminal 30
CR0232, VBBr
F 24
7.5 A
Terminal 30
Reserve
F 25 2 A Terminal 30 CR0232, programming interface
F 26
30 A
Terminal 30
Engine control unit
F 27
3 A
Terminal 15
Rexroth load limit sensing control
F 28
15 A
Terminal 15
Spark plug control unit
F 29
5 A
Terminal 15
CR0232 sensors, lubrication system, fan control: hydrau-
lic oil cooler, fan control: water-charge air cooler, air dif-
ferential pressure switch, slewing
F 30
5 A
Terminal 15
Multifunction display
