Chapter 5: OPERATION
2. EMERGENCY BROADCASTS
5-16
Step 3. If necessary, press the Talk key
to make announcements
from the Fireman's Microphone.
Because the Remote Microphone set for emergency
operation is given the highest priority, evacuation
guidance messages can be broadcast from the Fireman's
Microphone even during EV message broadcast.
Note
In Emergency mode, the talk key performs PTT (press-to-
talk) operation regardless of PC software setting.
3-1. When making microphone announcements over all zones
•Becauseallzonesarepre-selectedwheninemergency
mode, announcements made from the Remote
Microphones are broadcast to the entire zone.
•Because the Alert EV message is currently being
broadcast, the left-side Microphone Enable LED flashes
green to indicate that priority of current broadcast is
lower than that of microphone announcements.
•The right-side LED indicates the status of microphone
usage. It lights green when the Talk key is pressed.
Microphone LED
Microphone Enable LED
5
Talk key
Lights
To all zones
3-2. When making microphone announcements to selected
zones
•Becauseallzonesarepre-selectedwheninemergency
mode, press the All-Zone Call key
to cancel the all-
zone pre-selection. The zone selection is reset
and the Select LED extinguishes.
•Assuming that microphone announcements are
broadcast to 3F, the corresponding Zone Monitor LED is
flashing red because the Alert message is being
broadcast to 3F. Press the 3F Zone Select key
to
select the zone. The Select LED lights green.
Select LED
Select LED
Unused
4
All-Zone Call key
3F Zone Select key
Zone Monitor LED
Flashes
9
Continued on next page
To Next Page
