Programmers model
Table 5-40: GITS_OPR bit descriptions
Bits Name Description
[63:60] LOCK_TYPE Lock type supported:
0 Track
1 Trial
2 ITS lock
3 ITS unlock
4 Track abort
8 ITS unlock all
5‑7, 9‑15 Reserved
Note:
•
If GITS_OPSR.REQUEST_IN_PROGRESS == 1, when attempting a new access (other than
Track abort (4) during a Track) the behavior is unpredictable.
•
Invalidating the VCACHE by using GITS_FCTLR.XXX unlocks all the locked entries.
However, if a GITS_OPR lock request occurs while an invalidation is in progress
(GITS_FCTLR.XXX == 1), then it is unpredictable whether the entries remain locked when
the invalidation completes. This unpredictable behavior might cause GITS_OPSR to return
an incorrect status.
[59:52] - Reserved, RES0
[51:32] DEVICE_ID Sets the DeviceID. The number of bits that are implemented in this field is configuration
dependent. To determine the width of this field, software can read GITS_TYPER.DevBits.
[31:16] - Reserved, RES0
[15:0] EVENT_ID Sets the EventID. The number of bits that are implemented in this field is configuration
dependent. To determine the width of this field, software can read GITS_TYPER.IDBits.
5.6.5 GITS_OPSR, Operation Status Register
This register indicates cache lock status.
Configurations
This register is available in all configurations that have one or more ITS blocks.
Attributes
Width 64-bit
Functional group See 5.6 ITS control register summary on page 136 for the address offset,
type, and reset value of this register.
Usage constraints
There are no usage constraints.
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 144 of 268
