Revisions
Appendix C Revisions
This appendix describes the technical changes between released issues of this document.
Table C-1: Issue 0000-00
Change Location
First release -
Table C-2: Differences between issue 0000-00 and issue 0000-01
Change Location
Changed instances of qactive_clk_col to qactive_col_clk 3.5.4 SPI Collator clock Q-Channel on page 43
Updated bit assignments •
5.10.2 FMU_ERR<n>CTLR, Error Record Control
Register on page 180
•
5.10.3 FMU_ERR<n>STATUS, Error Record
Primary Status register on page 182
•
5.10.6 FMU_PINGCTLR, Ping Control Register
on page 185
•
5.10.7 FMU_PINGNOW, Ping Now register on
page 186
Replaced redundant table with reference to the Safety Manual 6.1 Safety Mechanism overview on page 193
Removed MSI-64 Encapsulator Safety Mechanism 6.2.5 Safety Mechanism IDs on page 199
Added list of Safety Mechanisms that cannot be disabled
through the FMU_SMEN register
6.2.5.1 Enabling or disabling a Safety Mechanism on
page 202
Added software procedure to initiate a directed ping 6.2.6 Ping mechanisms on page 202
Added section 6.2.8 Correctable Error enable on page 206
Added Prioritized FMU_ERR<n>STATUS registers content 6.2.9 Software interaction on page 207
Added section 6.10.4 Disabling P-Channel and Q-Channel Safety
Mechanisms on page 238
Added section 6.11 PPI and SPI interrupt interface protection on
page 244
Added FUSA_DISABLE_PQCHAN_PROT parameter.
Removed redundant information about FuSa parameters.
6.15 Configuration and parameters on page 248
Table C-3: Differences between issue 0000-01 and issue 0001-02
Change Location
Changed instances of:
•
DEVICEID_WIDTH to DID_WIDTH
•
num_cpus to cpus
•
num_ppis to ppi_count
•
num_its to its_count
Throughout the document
Added information to note 3.3 Interrupt Translation Service on page 34
Updated the ACE_LITE_ACCESS_FAILURE
description
4.15.6.7 ITS command and translation error records 13 and
beyond on page 81
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 265 of 268
