Programmers model
Bits Name Function
[19:16] Variant Indicates the major revision, or variant, of the product rmpn identifier:
0x0 r0
[15:12] Revision Indicates the minor revision of the product rmpn identifier:
0x1 p0
0x3 p1
0x4 p2
0x5 p3
[11:0] Implementer Identifies the implementer:
0x43B Arm
5.6.2 GITS_TYPER, ITS Type Register
This register returns information about the features that this ITS supports.
Configurations
This register is available in all configurations that have one or more ITS blocks.
Attributes
Width 64-bit
Functional group See 5.6 ITS control register summary on page 136 for the address offset,
type, and reset value of this register.
Usage constraints
There are no usage constraints.
Bit descriptions
Figure 5-30: GITS_TYPER bit assignments
31 24 23 20 19 18 17 13 12 8 7 4 3 2 1 0
IDBitsDevBitsReservedHCC
CIDBits
63 36 35 32
Reserved
37
CIL
Physical
Virtual
CCT
SEIS
PTA
ITTEntrySize
Reserved
