ARM CoreLink GIC-600AE User Manual

Arm
®
CoreLink™ GIC-600AE Generic Interrupt Controller
Technical Reference Manual
Document ID: 101206_0003_04_en
Issue: 04
Introduction
Figure 1-1: Key to timing diagram conventions
Signals
The signal conventions are:
Signal level
The level of an asserted signal depends on whether the signal is active-HIGH or active-LOW.
Asserted means:
•
HIGH for active-HIGH signals.
•
LOW for active-LOW signals.
Lowercase n
At the start or end of a signal name, n denotes an active-LOW signal.
1.4 Useful resources
This document contains information that is specific to this product. See the following resources for
other useful information.
Access to Arm documents depends on their confidentiality:
•
Non-Confidential documents are available at developer.arm.com/documentation. Each
document link in the following tables goes to the online version of the document.
•
Confidential documents are available to licensees only through the product package.
Arm product resources Document ID Confidentiality
Arm
®
CoreLink
™
ADB-400 AMBA
®
Domain Bridge User Guide
DUI 0615 Confidential
Arm
®
CoreLink
™
CMN-600 Coherent Mesh Network Technical Reference Manual
100180 Non‑Confidential
Arm
®
CoreLink
™
GIC-600AE Generic Interrupt Controller Configuration and Integration
Manual
101207 Confidential
Arm
®
CoreLink
™
GIC-600AE Generic Interrupt Controller Development Interface Report
101209 Confidential
Arm
®
CoreLink
™
GIC-600AE Generic Interrupt Controller Safety Manual
101208 Confidential
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 14 of 268
