Programmers model
Functional group See 5.2 Distributor registers (GICD/GICDA) summary on page 98 for the
address offset, type, and reset value of this register.
Usage constraints
There are no usage constraints.
Bit descriptions
Figure 5-13: GICD_PIDR3 bit assignments
CMODREVANDReserved
31 8 7 4 3 0
Table 5-15: GICD_PIDR3 bit descriptions
Bits Name Description
[31:8] - Reserved, RAZ
[7:4] REVAND Indicates minor errata fixes specific to the revision of the component being used, for example metal
fixes after implementation. 0x0 indicates that there are no errata fixes to this component.
0x0.
[3:0] CMOD Customer modified. Indicates whether the customer has modified the behavior of the component.
Usually, this field is 0x0. Customers change this value when they make authorized modifications to
this component.
0x0.
5.2.14 GICD_PIDR2, Peripheral ID2 register
This register returns byte[2] of the peripheral ID. The GICD_PIDR2 register is part of the set of
Distributor peripheral identification registers.
Configurations
This register is available in all configurations.
Attributes
Width 32-bit
Functional group See 5.2 Distributor registers (GICD/GICDA) summary on page 98 for the
address offset, type, and reset value of this register.
Usage constraints
There are no usage constraints.
