Page #198 background imageLoading...
Page #198 background image
Arm
®
CoreLink™ GIC-600AE Generic Interrupt Controller
Technical Reference Manual
Document ID: 101206_0003_04_en
Issue: 04
Functional Safety
6.2.3 Error record format
The FMU contains one error record for each GIC block.
GIC-600AE faults are recorded in error records.
The error record registers are accessible through a separate APB interface on the GICD. We expect
that there is a separate reset (Cold reset), so that the error record retains its state even when the
GIC block is being reset.
The following table lists the block IDs for each GIC block.
Table 6-1: Error record block IDs
Block ID GIC block
0 GICD
1 SPI Collator
2 Wake Request
3 Reserved
4 ITS0
5 ITS1
6 ITS2
7 ITS3
8 ITS4
9 ITS5
10 ITS6
11 ITS7
12 PPI0
13 PPI1
14 PPI2
15 PPI3
16 PPI4
17 PPI5
18 PPI6
19 PPI7
20 PPI8
21 PPI9
22 PPI10
23 PPI11
24 PPI12
25 PPI13
26 PPI14
27 PPI15
28 PPI16
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 198 of 268
