ARM CoreLink GIC-600AE User Manual

Arm
®
CoreLink™ GIC-600AE Generic Interrupt Controller
Technical Reference Manual
Document ID: 101206_0003_04_en
Issue: 04
Programmers model
5.4.1 GICR_IIDR, Redistributor Implementation Identification Register
This register provides information about the implementer and revision of the Redistributor.
Configurations
This register is available in all configurations.
Attributes
Width 32-bit
Functional group See 5.4 Redistributor registers for control and physical LPIs summary on page
121 for the address offset, type, and reset value of this register.
Usage constraints
There are no usage constraints.
Bit descriptions
Figure 5-19: GICR_IIDR bit assignments
Reserved RevisionVariant ImplementerProductID
31 024 1123 1220 19 16 15
Table 5-23: GICR_IIDR bit descriptions
Bits Name Function
[31:24] ProductID Indicates the product ID:
0x03 GIC-600AE
[23:20] - Reserved, RAZ
[19:16] Variant Indicates the major revision, or variant, of the product rmpn identifier:
0x0 r0
[15:12] Revision Indicates the minor revision of the product rmpn identifier:
0x1 p0
0x3 p1
0x4 p2
0x5 p3
[11:0] Implementer Identifies the implementer:
0x43B Arm
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 123 of 268
