sessions with QoS that are greater than 29000, a different SIP and SPA should be used to map to a different
QFP-3rd-Gen ASIC. This will enable additional schedules and queues.
Features of the Cisco ASR 1000 Series Embedded Services
Processors
The following table summarizes the features of the embedded services processors.
Table 36: Differences in Cisco ASR 1000 Series Embedded Services Processors
Security Traffic
Performance
BandwidthPerformanceMemoryEmbedded Services
Processor
1 Gbps5 Gbps4 Mpps for the
combination of the
following
commonly-used
features: IPv4
forwarding, IP
Multicast, ACL,
QoS, Reverse Path
Forwarding (RPF),
load balancing, and
Sampled NetFlow
256MB Cisco
QuantumFlow
Processor, 5Mb
TCAM, 64 MB
packet buffer, and 1
GB FECP DRAM
Cisco
ASR1000-ESP5
3 Gbps10 Gbps8 Mpps forwarding
for the combination
of the following
commonly-used
features: IPv4
forwarding, IP
Multicast, ACL,
QoS, Reverse Path
Forwarding (RPF),
load balancing, and
Sampled NetFlow
512MB Cisco
QuantumFlow
Processor, 10Mb
TCAM, and 128MB
packet buffer, and 2
GB FECP DRAM
Cisco
ASR1000-ESP10
8 Gbps20 Gbps16 Mpps forwarding
for the combination
of the following
commonly-used
features: IPv4
forwarding, IP
Multicast, ACL,
QoS, Reverse Path
Forwarding (RPF),
load balancing, and
Sampled NetFlow
1 GB Cisco
QuantumFlow
Processor, 40Mb
TCAM, 256 MB
packet buffer, 4 GB
FECP DRAM
Cisco
ASR1000-ESP20
Cisco ASR 1000 Series Router Hardware Installation Guide
94
Cisco ASR 1000 Series Routers Embedded Services Processors
Features of the Cisco ASR 1000 Series Embedded Services Processors

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
