DescriptionPower Cord Item Number
Power Cord Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord UK, Right AngleCAB-ACU-RA
Power Cord India, Right AngleCAB-IND-RA
Power Cord-Japan, Right AngleCAB-JPN-RA
Installation Methods
Cisco ASR 1001 Router is designed for standalone, two rail 19-inch rack-mount (front rail only), four rail
19-inch rack-mount (front and rear rail).
Although rack-mounting is the preferred method of installation for the Cisco ASR 1001 Router, you can
mount the chassis on an equipment shelf or tabletop.
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each warning
to locate its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information
for Cisco ASR 1000 Series Aggregation Services Routers publication. This document provides important
safety information you should know before working with the system. Statement 200
Warning
You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
Note
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
•
The Cisco ASR 1001 Router requires a minimum of 3.5 inches or 8.9 cm rack units of vertical rack
space. Measure the proposed rack location before mounting the chassis in the rack.
•
Before using a particular rack, check for obstructions (such as a power strip) that could impair rack-mount
installation. If a power strip does impair a rack-mount installation, remove the power strip before installing
the chassis, and then replace it after the chassis is installed.
Cisco ASR 1000 Series Router Hardware Installation Guide
425
Cisco ASR 1001 Router Overview and Installation
Installation Methods

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
