Cisco ASR 1004 Hardware Installation Guide

DescriptionChapter and Appendix
This chapter describes the Cisco ASR 1002-X router and how to install it.
Chapter 10, “Cisco ASR 1002-X
Router Overview and
Installation"
This chapter describes the Cisco ASR 1013 router and how to install it.
Chapter 11, “Cisco ASR 1013
Router Overview and
Installation"
This chapter describes the Cisco ASR 1001 router and how to install it.
Chapter 12, “Cisco ASR 1001
Router Overview and
Installation"
This chapter provides basic system startup and initial configuration
information.
Chapter 13, “Cisco ASR 1000
Series Routers Power Up and
Initial Configuration"
This chapter provides instructions for removing and replacing shared port
adapters, ASR 1000 RP1 internal hard drive, AC and DC power supplies,
the Cisco ASR 1000 ESP forwarding processors, the Cisco DIMM memory
cards, the Cisco memory stick, and the Cisco ASR 1000 Series Route
Processors.
Chapter 14, “Removing and
Replacing FRUs from the Cisco
ASR 1000 Series Routers"
This appendix provides system specifications and pinouts.
Appendix A, “Cisco ASR 1000
Series Router Specifications"
This appendix lists pinout specifications for the Cisco ASR1000-RP1 and
the Cisco ASR1000-RP2.
Appendix B, “Cisco ASR 1000
Series Router Route Processor
and Embedded Services
Processor Signals and Pinouts"
This appendix provides basic system startup troubleshooting information.Appendix C, "Troubleshooting
Initial Startup Problems"
This appendix lists the MIBs that can be used to manage the Cisco ASR
1001 Router.
Appendix D, "MIBs for the
Cisco ASR 1001 Router"
The glossary lists Cisco ASR 1000 Series Routers terms with definitions.Glossary
Conventions
This document uses the following conventions:
IndicationConvention
Commands and keywords and user-entered text
appear in bold font.
bold font
Cisco ASR 1000 Series Router Hardware Installation Guide
xxv
Preface
Conventions

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
