Cisco ASR 1004 Hardware Installation Guide

CHAPTER 7
Cisco ASR 1004 Router Overview and Installation
This chapter describes the Cisco ASR 1004 Router and the procedures for installing the Cisco ASR 1004
Router on an equipment shelf or tabletop or in equipment racks. It also describes how to connect interface
and power cables.
This chapter contains the following sections:
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each warning
to locate its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information
for Cisco ASR 1000 Series Aggregation Services Routers publication. This document provides important
safety information you should know before working with the system. Statement 200
Warning
•
Cisco ASR 1004 Router Description, page 182
•
Installation Methods, page 186
•
General Rack Installation Guidelines, page 186
•
Guidelines for an Equipment Shelf or Tabletop Installation, page 187
•
Equipment Shelf or Tabletop Installation, page 188
•
Rack-Mounting the Cisco ASR 1004 Router, page 190
•
Attaching the Chassis Rack-Mount Brackets, page 192
•
Installing the Cisco ASR 1004 Router in a Rack, page 195
•
Attaching a Chassis Ground Connection, page 201
•
Attaching the Cable-Management Bracket, page 204
•
Connecting the Shared Port Adapter Cables, page 205
•
Connecting the Console and Auxiliary Port Cables, page 206
