Cisco ASR 1004 Hardware Installation Guide

Two-Post Rack Installation
The Cisco ASR 1004 Router can be installed on a two-post rack, either 19 inch or 23 inch.
Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches
(48.26cm). The height of the chassis is 6.95 inches (17.653 cm). Airflow through the chassis is from front
to back.
Note
If you are using a two-post rack secure the rack to the floor surface to prevent tipping and avoid bodily
injury and component damage.
Caution
SUMMARY STEPS
1.
Position the chassis so the front is closest to you and lift it carefully into the rack. To prevent injury, avoid
any sudden twists or moves.
2.
Slide the chassis into the rack, pushing it back until the brackets meet the mounting strips or posts on both
sides of the rack.
3.
Keeping the brackets flush against the posts or mounting strips, align the holes in the brackets with the
holes on the rack or mounting strip.
4.
For each bracket, insert and tighten two screws to the rack on both sides.
DETAILED STEPS
Step 1
Position the chassis so the front is closest to you and lift it carefully into the rack. To prevent injury, avoid any sudden
twists or moves.
Cisco ASR 1000 Series Router Hardware Installation Guide
197
Cisco ASR 1004 Router Overview and Installation
Two-Post Rack Installation

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
