a) Insert the bottom screw into the second bracket ear hole up from the bottom of the rack-mount ear and use a hand-held
screwdriver to tighten the screw to the rack rail.
b) Insert the top screw into the second bracket ear hole from the top of the rack-mount ear diagonally from the bottom
screw and tighten the screw to the rack rail.
c) Insert the four screws to secure the chassis to the rack equipment.
As a result of using the specified rack-mount bracket ear holes, the cable-management bracket can be easily
attached to the rack-mount bracket when the chassis is in the rack.
Tip
Step 8
Tighten all screws on each side to secure the chassis to the equipment rack.
What to Do Next
You can install your Cisco ASR 1002-F Router on a two-post or four-post rack. See the “Two-Post Rack
Installation” or the “Four-Post Rack Installation.”
Two-Post Rack Installation
The Cisco ASR 1002-F Router can be installed on a two-post rack, either a 19-inch or 23-inch rack.
Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches
(48.26 cm). The height of the chassis is 3.47 inches (8.8 cm). Airflow through the chassis is from front to
back.
Note
If you are using a two-post rack, secure the rack to the floor surface to prevent tipping and avoid bodily
injury and component damage.
Caution
Step 1
Position the chassis so the front is closest to you and lift it carefully into the rack. To prevent injury, avoid any sudden
twists or moves.
Cisco ASR 1000 Series Router Hardware Installation Guide
297
Cisco ASR 1002-F Router Overview and Installation
Two-Post Rack Installation
