Cisco ASR 1004 Hardware Installation Guide

Verifying the Hardware Configuration
To display and verify the hardware features, enter the following commands:
• show version—Displays the system hardware version; the installed software version; the names and
sources of configuration files; the boot images; and the amount of installed DRAM, NVRAM, and flash
memory.
• show diag chassis—Displays the IDPROM information for the assemblies in the chassis.
• show diag slot/subslot—Displays the IDPROM information for the subassemblies in the chassis.
Checking Hardware and Software Compatibility
To check the minimum software requirements of the Cisco IOS software with the hardware installed on your
Cisco ASR 1000 Series Routers, Cisco maintains the Software Advisor tool on Cisco.com. This tool does not
verify whether Cisco ASR 1000 Series SIPs or SPAs within a system are compatible; but the tool provides
the minimum Cisco IOS requirements for individual hardware modules and components.
To access this tool, you must have a Cisco.com login account.Note
To access the Software Advisor, click Login at Cisco.com, type Software Advisor in the search box, and
click Go. Click the link for the Software Advisor Tool.
Choose a product family or enter a specific product number to search for the minimum supported software
needed for your hardware.
Configuring the Cisco ASR 1000 Series Routers at Startup
This section explains how to create a basic running configuration for your Cisco ASR 1000 Series Routers.
You need to acquire the correct network addresses from your system administrator or consult your network
plan to determine correct addresses before you can complete the router configuration.
Note
Before continuing the configuration process, check the current state of the router by entering the show version
command. The show version command displays the release of Cisco IOS software that is available on the
router.
For information on modifying the configuration after you create it, see the Cisco IOS configuration and
command reference guides.
To configure a Cisco ASR 1000 Series Routers from the console, you must connect a terminal or terminal
server to the console port. To configure the Cisco ASR 1000 Series Routers over your management Ethernet,
you must have the router’s IP address available.
Cisco ASR 1000 Series Router Hardware Installation Guide
467
Cisco ASR 1000 Series Routers Power Up and Initial Configuration
Verifying the Hardware Configuration

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
