Cisco ASR 1004 Hardware Installation Guide

DescriptionDirectionSignalPin
——
NC7,8
Cisco ASR 1006 Router BITS Port Signals and Pinouts
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) RJ45 port on the Cisco
ASR 1006 Router.
Table 98: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive (T1/E1)InputRX2
——
N/C3, 4
—
UnusedTX Ring5
—
UnusedTX6
——
N/C7,8
The following table lists the pinouts of the Building Integrated Timing Supply (BITS) and the DOCSIS Timing
Interface (DTI) RJ45 port on the Cisco ASR1000-RP2 front panel.
Table 99: BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
DescriptionDirectionSignalPin
Receive
Ring/Bidirectional DTI
Input/Bi (DTI)RX Ring1
Receive TIP (T1/E1)
Bidirectional DTI
Input/Bi (DTI)RX TIP2
——
N/C3, 4
Transmit
Ring/Bidirectional DTI
OutputTX Ring5
Transmit TIP (T1/E1)
Bidirectional DTI
OutputTX6
——
N/C7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
618
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1006 Router BITS Port Signals and Pinouts

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
