Cisco ASR 1004 Hardware Installation Guide

SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
—
1745Minor Audible
Alarm
MINAA
—
18619Critical Visual
Alarm
CRTVA
—
2078Major Visual
Alarm
MAJVA
—
21922Minor Visual
Alarm
MINVA
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco ASR
1002-X Router Specifications
This section lists the specifications for the Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco
ASR 1002-X Router.
Unless stated otherwise, the specifications for the Cisco ASR 1002-F Router are the same as those for the
Cisco ASR 1002 Router except where limited by constrained throughput of 2.5G on the Cisco ASR 1002-F
Router.Similarly, most of the specifications for the Cisco ASR 1002-X Router are the same as the
specifications for the Cisco ASR 1002 Router. The differences in specifications have been called out at
the relevant places in this section. Some of the Cisco ASR 1002-X Router specifications that are covered
in this section are for ports that are specific to that router.
Note
The following table lists the Cisco ASR 1002 Router physical specifications.
Table 110: Cisco ASR 1002 Router Specifications
SpecificationDescription
Connects the Cisco integrated ASR1000-RP1, the ASR 1000
ESP5 or ESP10, SPAs, and power supplies together in the system
Midplane
Cisco ASR 1000 Series Router Hardware Installation Guide
625
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco ASR 1002-X Router Specifications

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
