Cisco ASR 1013 Router Memory and Storage Options
The following table lists the hardware memory and storage options supported on the Cisco ASR 1013 Router.
Table 119: Memory and Storage Options for Cisco ASR 1013 Router
Maximum System SupportDefaultMemory Type
8 GB8 GB
R21– DRAM
2 GB1 GB for ASR1000-ESP-5
2 GB for ASR1000-ESP10
FECP – DRAM
8 GB – Not Field Upgradeable
8 GB on the integrated RP on the Cisco
ASR 1002 Router (partitioned: 1 GB for
bootflash; 7 GB for mass storage)
eUSB – Internal Flash + NVRAM
Cisco ASR 1013 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1013 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially.
Cisco ASR 1013 Router MGMT Ethernet Port Signals and Pinouts
The following table lists the RJ-45 port pinout for the front panel Management Ethernet port.
Table 120: Management Ethernet 10/100/1000 RJ-45 Port Pinouts for Cisco ASR 1013 Router
DescriptionDirectionSignalPin
Transmit DataOutputTX Data+1
Transmit DataOutput
TX Data–
2
Receive DataInputRX Data+3
——
NC4, 5
Receive DataInput
RX Data–
6
——
NC7,8
Cisco ASR 1000 Series Router Hardware Installation Guide
632
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1013 Router Memory and Storage Options

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
