Cisco ASR 1004 Hardware Installation Guide

SUMMARY STEPS
1.
Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
2.
Remove the new Cisco ASR1000-ESP from its static shielding bag.
3.
Using both hands, grasp the Cisco ASR1000-ESP by its metal carrier edges and orient the it so that its
printed circuit board components are upward.
4.
Align the left and right edges of the Cisco ASR1000-ESP printed circuit board between the Cisco
ASR1000-ESP slot guides.
5.
Gently slide the Cisco ASR1000-ESP all the way into its chassis slot until you feel the connectors seat
with the router midplane.
6.
Seat the Cisco ASR1000-ESP in the router midplane by tightening its captive installation screws with a
number 2 Phillips or a 3/16-inch flat-blade screwdriver.
DETAILED STEPS
Step 1
Attach an ESD-preventive wrist strap between you and an unfinished chassis surface.
Step 2
Remove the new Cisco ASR1000-ESP from its static shielding bag.
Step 3
Using both hands, grasp the Cisco ASR1000-ESP by its metal carrier edges and orient the it so that its printed circuit
board components are upward.
Handle the Cisco ASR1000-ESP by the carrier edges and handle only; never touch the printed circuit board
components or connector pins.
Caution
Step 4
Align the left and right edges of the Cisco ASR1000-ESP printed circuit board between the Cisco ASR1000-ESP slot
guides.
Step 5
Gently slide the Cisco ASR1000-ESP all the way into its chassis slot until you feel the connectors seat with the router
midplane.
Step 6
Seat the Cisco ASR1000-ESP in the router midplane by tightening its captive installation screws with a number 2 Phillips
or a 3/16-inch flat-blade screwdriver.
What to Do Next
This completes the procedure for replacing the Cisco ASR1000-ESP in the Cisco ASR 1000 Series Router.
Removing and Replacing Cisco ASR 1000 Series Router SPAs
and SPA Interface Processors
This section contains the following topics:
For detailed information about SIP and SPA software commands such as activating and deactivating SIPs,
prepare for online insertion and removal of SPAs, and activate and deactivate configuration examples,
see Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Hardware Installation Guide .
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
533
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Router SPAs and SPA Interface Processors

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
