Cisco ASR 1004 Hardware Installation Guide

•
Have access to the Cisco ASR 1000 Series Aggregation Services Routers Software Configuration Guide
(an online document that is available for viewing or download at Cisco.com) during the installation.
•
The power and cabling requirements that must be in place at your installation site
•
The equipment required to install the router
•
The environmental conditions your installation site must meet to maintain normal operation
Before installing your Cisco ASR 1000 Series Aggregation Services Router, you must consider power and
cabling requirements that must be in place at your installation site, special equipment for installing the router,
and the environmental conditions your installation site must meet to maintain normal operation. This chapter
guides you through the process of preparing for router installation.
The shipping package for the router is engineered to reduce the chances of product damage associated with
routine material handling experienced during shipment:
•
Router should always be transported or stored in its shipping package in the upright position.
•
Keep the router in the shipping container until you have determined the installation site.
Inspect all items for shipping damage. If an item appears damaged, contact a Cisco customer service
representative immediately.
Note
Safety Guidelines
Before you begin the installation or replacement procedure, review the safety guidelines in this section to
avoid injuring yourself or damaging the equipment.
This section contains guidelines and do not include every potentially hazardous situation. When you install
a router, always use common sense and caution.
Note
Safety Warnings
Safety warnings appear throughout this publication in procedures that, if performed incorrectly, might harm
you. A warning symbol precedes each warning statement.
Before you install, configure, or perform maintenance on the router, review the documentation for the procedure
you are about to perform, paying special attention to the safety warnings. If you need translations of the safety
warnings.
Do not unpack the system until you are ready to install it. Keep the chassis in the shipping container to
prevent accidental damage until you determined an installation site. Use the appropriate unpacking
documentation included with the system.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
112
Preparing Your Site for Installation
Safety Guidelines

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
