Cisco ASR 1004 Hardware Installation Guide

1PPS (input and output)10 Mhz (input and output)Signal Attribute
40 nanoseconds
Input—AC coupled
Output—5 nanoseconds
Rise Time
Cisco ASR 1002-X Router Time of Day Port Pinout
The following table summarizes the pinout of the ToD/1PPS port pinout on the Cisco ASR 1002-X.
Table 117: RJ45 1PPS/ToD Port Pinout
DescriptionDirectionSignal NamePin
1PPS RS422 signalOutput or Input1PPS_P1
1PPS RS422 signalOutput or Input1PPS_N2
Do not use this pin.OutputRESERVED3
GND4
Time of Day characterGND5
Do not use this pin.InputRESERVED6
Time of Day characterOutput or InputTOD_P7
Time of Day characterOutput or InputTOD_N8
Cisco ASR 1013 Router Specifications
This section lists the specifications for the Cisco ASR 1013 Router. The following table lists the Cisco ASR
1013 Router physical specifications.
Table 118: Cisco ASR 1013 Router Specifications
SpecificationDescription
Connects Cisco ASR1000-RP2, Cisco ASR 1000-ESP40 or Cisco
ASR 1000-ESP100, Cisco ASR1000-SIP10 and Cisco
ASR1000-SIP40, and power supplies together in the system
Midplane
Cisco ASR 1000 Series Router Hardware Installation Guide
630
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002-X Router Time of Day Port Pinout

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
