Cisco ASR 1004 Hardware Installation Guide

SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1004 Router Specifications
This section lists the specifications for the Cisco ASR 1004 Router.
The following table lists the Cisco ASR 1004 Router physical specifications.
Table 103: Cisco ASR 1004 Router Specifications
SpecificationDescription
Connects the Cisco ASR 1000 Series RP1, ASR 1000 Series ESP,
Cisco ASR 1000 Series SPA Interface (SIP), SPAs, and power
supplies together in the system
Midplane
Height = 7 in. (17.8 cm) (4RU rack-mount per EIA RS-310)
Width = 17.25 in. (43.815 cm) (19 inch rack-mount or optional
23 Telco rack- mount)
Depth = 22.50 in. (57.15 cm) (including card handles,
cable-management brackets and power supply handles)
Dimensions (H x W x D)
•
Fully loaded chassis: 50 pounds (22.6796 kg)
•
Only chassis: 18 pounds (8.16 kg)
Weight
•
41° to 104° F
•
5° to 40° C
Nominal operating temperature
10% to 85%Nominal operating humidity
• –38° to 150° F
• –40° to 70° C
Storage temperature
•
Maximum DC: 1020W
•
Maximum AC: 960W
•
Maximum (Out): 765W
Power consumption
Cisco ASR 1000 Series Router Hardware Installation Guide
621
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router Specifications

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
