Cisco ASR 1004 Hardware Installation Guide

Cisco ASR 1006 Router Console Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the front panel console port.
Table 100: Console Port Pinouts for Cisco ASR 1006 Router
DescriptionDirectionSignalPin
Request to Send (tied to
pin 8, CTS)
OutRTS1
Data Terminal Ready
(always On)
OutDTR2
Transmit DataOutTXD3
Ring Indicator
—
GND4
——
GND5
Receive DataInRXD6
Data Terminal ReadyInDSR7
Clear to Send (tied to pin
1, RTS)
InCTS8
Cisco ASR 1006 Router Auxiliary Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the auxiliary port signals.
Table 101: Auxiliary Port Pinouts for Cisco ASR 1006 Router
DescriptionDirectionSignalPin
Request to SendOutRTS1
Data Terminal Ready
(always On)
OutDTR2
Transmit DataOutTXD3
Ring Indicator
—
RI4
——
GND5
Cisco ASR 1000 Series Router Hardware Installation Guide
619
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1006 Router Console Port Signals and Pinouts

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
