SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
—
1745Minor Audible
Alarm
MINAA
—
18619Critical Visual
Alarm
CRTVA
—
2078Major Visual
Alarm
MAJVA
—
21922Minor Visual
Alarm
MINVA
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1001 Router Specifications
This section lists the specifications for the Cisco ASR 1001 Router. The following table lists the Cisco ASR
1001 Router physical specifications.
The Cisco ASR 1001 Router has the route processor, embedded services processor, and SIP integrated in
the chassis.
Note
Table 125: Cisco ASR 1001 Router Specifications
SpecificationDescription
Height: 1.71 in. (43.43 mm)
Width: 17.3 in. (439.42 mm)
Depth: 22.50 in. (571.5 mm) including card handles,
cable-management brackets, and power supply
handles)
Dimensions (H x W x D)
•
23.30 lb (10.6 kg) (with dual AC power and
integrated daughter card)
•
22.70 lb (10.3 kg) (with dual DC power and
integrated daughter card)
•
25 lb fully loaded
Weight
Cisco ASR 1000 Series Router Hardware Installation Guide
635
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1001 Router Specifications

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
