Cisco ASR 1004 Hardware Installation Guide

After several attempts, if the system fails to restart properly, contact a service representative for assistance.
Before you call, make note of any error messages, unusual LED states, or other indications that might
help solve the problem.
Note
Removing and Replacing the Cisco ASR 1002-X Router DIMM Memory Modules
Perform the following steps before you begin:
•
Use an ESD-preventive wrist strap.
•
Back up data that you want to save before replacing a eUSB device.
•
Note that the component is keyed and slotted for easier connection.
•
To ensure that the DIMMs function correctly, all the DIMMs must be replaced at the same time. In
addition, you must ensure that all the DIMMs are from the same manufacturer and have the same part
number, because manufacturers may have multiple versions of a DIMM.
The following table shows the slots that are supported for inserting memory DIMMs in the Cisco ASR1002-X
Router.
Table 93: Cisco ASR1002-X Router Supported Slots for Inserting Memory DIMMs
Slot 3 (U1D1)Slot 2 (U1D0)Slot 1 (U2D1)Slot 0 (U2D0)Memory PID Option
—
2 GB module
—
2 GB moduleM-ASR1002X-4GB
2 GB Module2 GB Module2 GB Module2 GB ModuleM-ASR1002X-8GB
4 GB Module4 GB Module4 GB Module4 GB ModuleM-ASR1002X-16GB
To ensure vendor and MPN compatibility during memory upgrades, remove the installed DIMMs and
replace them with the DIMMs provided in the upgrade kit.
Note
Cisco ASR 1000 Series Router Hardware Installation Guide
514
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing the Cisco ASR 1002-X Router DIMM Memory Modules

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
