This unit has two power supply connections. All connections must be removed to de-energize the unit.
Statement 1028
Warning
This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than: AC power supplies 20 A and DC power supplies 30 A. Statement
1005
Warning
This section provides the procedures for connecting AC-input, –48 VDC input power, and the +24 VDC input
power to your Cisco ASR 1002 Router.
Detailed instructions for removing and replacing the Cisco ASR 1002 Router AC and DC power supplies
are in Chapter 14, “Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers.”
Note
Connecting AC Input Power to Cisco ASR 1002 Router
To connect AC power to the Cisco ASR 1002 Router, follow these steps:
SUMMARY STEPS
1.
At the rear of the router, check that the power switch is in the Off (O) position.
2.
Insert the AC power cable into the power supply AC inlet.
3.
To ensure that the AC power cord does not interfere with other cables or wires, dress the AC power cable
in one of the following ways.
4.
Plug the AC power supply cable into the AC power source.
DETAILED STEPS
Step 1
At the rear of the router, check that the power switch is in the Off (O) position.
Turn the power switch to the On (|) position after both sides of the power cord are connected.Note
Cisco ASR 1000 Series Router Hardware Installation Guide
256
Cisco ASR 1002 Router Overview and Installation
Connecting AC Input Power to Cisco ASR 1002 Router
