Cisco ASR 1004 Hardware Installation Guide

Table 136: Console Port Pinout for Cisco ASR1000-ESP100
DescriptionDirectionSignalPin
Request to send, tied to
CTS
INRTS1
UnusedOUTDTR2
Transmit dataOUTTXD3
GroundGroundGND4
GroundGroundGND5
Receive dataINRXD6
UnusedINDSR7
Clear to send, tied to RTSOUTCTS8
Cisco ASR1000-ESP200 Console Port Pinout Specifications
Cisco ASR1000-ESP200 provides a debug console on an 8-pin header. The following table lists the console
port pinouts for Cisco ASR1000-ESP200.
Table 137: Console Port Pinout for Cisco ASR1000-ESP200
DescriptionDirectionSignalPin
Request to send, tied to
CTS
INRTS1
UnusedOUTDTR2
Transmit dataOUTTXD3
GroundGroundGND4
GroundGroundGND5
Receive dataINRXD6
UnusedINDSR7
Clear to send, tied to RTSOUTCTS8
Cisco ASR 1000 Series Router Hardware Installation Guide
643
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Cisco ASR1000-ESP200 Console Port Pinout Specifications

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
