Cisco ASR 1004 Hardware Installation Guide

AC power supply
Standby switch. A
Standby switch is not
considered a disconnect.
7Cable tie wrap tabs3
AC power supply LEDs8AC power supply captive
screws
4
Internal fans draw cooling air into the chassis and across internal components to maintain an acceptable
operating temperature. (See Figure 35: Cisco ASR 1006 Router Rear View with the AC Power Supply
(ASR1006-PWR-AC), on page 141.) The fans are located at the rear of the chassis. A two-hole grounding
lug is located on the side of the chassis. Two power supplies, either two AC power supplies or two DC power
supplies, are accessed from the rear of the router.
You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
Note
Do not combine AC and DC power supplies in the same chassis.Note
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the statement number provided at the end of each warning
to locate its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information
for Cisco ASR 1000 Series Aggregation Services Routers publication. This document provides important
safety information you should know before working with the system. Statement 200
Warning
You have already unpacked your chassis and read all the site requirements for your new equipment.
Proceed with the installation.
Note
Cisco ASR 1006 Router Slot Numbering
The Cisco ASR 1006 Router is designed with each slot numbered as shown in Figure 36: Cisco ASR 1006
Router — Slot Numbering, on page 142.
Figure 36: Cisco ASR 1006 Router — Slot Numbering
Cisco ASR 1000 Series Router Hardware Installation Guide
142
Cisco ASR 1006 Router Overview and Installation
Rear View
