Cisco ASR 1002 Router Auxiliary Port Signals and Pinouts
Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
Note
The following table lists the pinout of the dual RJ-45 ports for the auxiliary port signals.
Table 113: Auxiliary Port Pinouts for Cisco ASR 1002 Router
DescriptionDirectionSignalPin
Request to SendOutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
RI4
——
GND5
Receive DataInputRXD6
Data Set Ready/Data
Carrier Detect
InputDSR/DCD7
Clear to SendInputCTS8
Cisco ASR 1002 Router BITS Port Signals and Pinouts
The following table lists the pinout of the front panel Building Integrated Timing Supply (BITS) RJ45 port.
Table 114: BITS RJ-45 Interface Pinouts for Cisco ASR 1002 Router
DescriptionDirectionSignalPin
Receive RingInputRX Ring1
Receive TIP (T1/E1)InputRX TIP2
Not used
—
N/C3, 4
Not used
—
TX Ring5
Not used
—
TX TIP6
Cisco ASR 1000 Series Router Hardware Installation Guide
628
Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router Auxiliary Port Signals and Pinouts

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
