Cisco ASR 1004 Hardware Installation Guide

fiber cables for the PA-POS-OC3 port adapter, see PA-POS-OC3 Port Adapter Installation and Configuration
at :
http://www.cisco.com/en/US/partner/docs/interfaces_modules/port_adapters/install_upgrade/pos/
pa-pos-oc3_install_config/paposoc3.html
Connecting the Console and Auxiliary Port Cables
This section describes how to attach a cable to the console ports or auxiliary ports on the Cisco ASR 1002-X
Router. This router uses RJ-45 ports for both the auxiliary port and the console port. On the front panel of the
router, the integrated route processor console port and auxiliary port are labeled CON and AUX, respectively.
To meet Class A emission requirements, shielded cables must be used for the console and auxiliary port
connectors.
Caution
Before using the console interface on the router via a terminal or PC, you must perform the following steps:
SUMMARY STEPS
1.
Before connecting a terminal to the console port, configure the terminal to match the chassis console port
as follows: 9600 baud, 8 data bits, no parity, 1 stop bits (9600 8N1).
2.
Connect to the port using the RJ-45 to DB-9 cable.
3.
After you establish normal router operation, disconnect the terminal, if required.
DETAILED STEPS
Step 1
Before connecting a terminal to the console port, configure the terminal to match the chassis console port as follows:
9600 baud, 8 data bits, no parity, 1 stop bits (9600 8N1).
Step 2
Connect to the port using the RJ-45 to DB-9 cable.
For information about how to change the default settings to meet the requirements of your terminal or host, see
the Cisco IOS Terminal Services Configuration Guide .
Note
Step 3
After you establish normal router operation, disconnect the terminal, if required.
Management Ethernet Port Cable Connection
To comply with Class A emission requirements, a shielded Ethernet cable must be used for the connection.Caution
On the front panel of the router, the Management Ethernet port is labeled MGMT ETHERNET. To use the
Management Ethernet interface on the router, perform the following steps:
Cisco ASR 1000 Series Router Hardware Installation Guide
350
Cisco ASR 1002-X Router Overview and Installation
Connecting the Console and Auxiliary Port Cables

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
