Cisco ASR 1004 Hardware Installation Guide

•
Cisco ASR 1000 Series route processors: RP1 and RP2
•
Cisco ASR 1000 Series embedded services processors: Cisco ASR1000-ESP5, Cisco ASR1000-ESP10,
Cisco ASR1000-ESP20, Cisco ASR1000-ESP40, Cisco ASR1000-ESP100, and Cisco ASR1000-ESP200.
•
Shared port adapters
•
Cisco ASR 1000 Series shared port adapter interface processors (SIPs)
•
Cisco ASR 1000 Series RP1 internal hard drive
•
Cisco ASR 1000 Series RP1 DIMM memory module (Note that the integrated Cisco ASR1000-RP1 on
the Cisco ASR 1002 Router DIMM memory module is not field-replaceable.)
•
USB flash token memory stick
•
AC and DC power supplies
• Bracket kit—Custom cable-management brackets are mounted to each rack-mount bracket to provide
cable management to both sides of the chassis (parallel with card orientation). These brackets are
screw-mounted to the rack brackets to enable easy installation and removal. There is a rack-mount
bracket for each chassis:
◦
For the Cisco ASR 1006 Router, the cable-management brackets contain five independent
cable-management U features to provide cable dressing for each card module slot. For SIPs, these
brackets work in tandem with SPA product feature cable management to allow installation and
removal of adjacent cards without having to remove cables.
◦
For the Cisco ASR 1004 Router, the cable-management brackets contain three independent
cable-management U features to provide cable dressing for each card module slot. For SIPs, these
brackets work in tandem with SPA product feature cable management to allow installation and
removal of adjacent cards without having to remove cables.
◦
For the Cisco ASR 1002 Router, the cable-management brackets contains one independent
cable-management U feature to provide cable dressing for each card module slot. These brackets
work in tandem with SPA product feature cable management to allow installation and removal of
adjacent cards without having to remove cables.
The Cisco ASR 1002-F Router and Cisco ASR 1002-X Router use the same accessories as the Cisco ASR
1002 Router.
Note
•
For the Cisco ASR 1013 Router, the cable-management brackets contain four independent
cable-management U features to provide cable dressing for modules. There are two brackets with
four U-feature hooks for each side of the chassis.
◦
◦
For the Cisco ASR 1001 Router, the cable-management bracket contains one independent
cable-management U feature to provide cable dressing for each card module slot.
Functional Overview
This section contains the following topics:
Cisco ASR 1000 Series Router Hardware Installation Guide
8
Cisco ASR 1000 Series Routers Hardware Overview
Functional Overview

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
