Cisco ASR 1004 Hardware Installation Guide

Cisco ASR 1000 Series Router
Power Supply
SymbolSwitch Type Supported
ASR 1006 AC
ASR 1004 AC
ASR 1002 –48 VDC
ASR 1002 +24 VDC
ASR 1013 AC and DC
ASR 1001 AC and DC
ASR 1002-X –48 VDC
ASR 1002-X +24 VDC
A broken circle with a vertical line
through the top of it
Standby switch
AC and DC System Power Ratings
The following table lists AC and DC power supply system rating requirements for all Cisco ASR 1000 Series
Routers.
Table 16: AC and DC Power Supply System Rating Specifications for the Cisco ASR 1000 Series Routers
SpecificationDescription
AC = 100-240 VACPower supply declared ratings
DC = –48/ –60 VDC
+24 VDC = +21 / +36 VDC
50/60 Hz for AC power suppliesNominal line frequency rating
Power Supplies for the Cisco ASR 1006 Router
The information in this section applies to the ASR1006-PWR-DC and ASR1006-PWR-AC power supplies.
The Cisco ASR 1006 Router also supports the ASR1013/06-PWR-DC and ASR1013/06-PWR-AC power
supplies, which are described in the Power Supplies for the Cisco ASR 1013 Router, on page 76.
Note
The Cisco ASR 1006 Router can support up to 1200 W output (AC and –48 VDC input). The 1200 W power
supply module consists of either an AC or –48 VDC input and 1200 watt output closed frame power supply
with two DC voltage outputs: 12 V and 3.3 V.
Each power supply module contains three internal fan modules and provides the forced air cooling for the
chassis. These power supply modules contain a monitor circuit to determine the status of fan speed and
operation along with LED status indicating fan errors.
Cisco ASR 1000 Series Router Hardware Installation Guide
51
Cisco ASR 1000 Series Routers Component Overview
AC and DC System Power Ratings
