SUMMARY STEPS
1.
Connect one end of the RJ-45 cables to the serial RJ-45 port (CON) on the Cisco embedded ASR1000-RP1
(see “Common Connectors for Cisco ASR 1001 Route Processor” in the Cisco ASR 1001 Router Faceplate
Common Components section).
2.
Run the cable up and through the cable-management bracket and connect the other end of the RJ-45 cable
to the RJ-45 adapter (see “Cisco ASR 1001 Router AC Power Supply and DC Power Supply” figure in
the Cisco ASR 1001 Router Power Supply Installation section).
3.
Connect the adapter to your video terminal to complete the cable connection.
4.
Power on your video terminal.
5.
Configure your video terminal to match the following default console port settings:
6.
Go to the Connecting Cables, on page 443 to continue the installation.
DETAILED STEPS
Step 1
Connect one end of the RJ-45 cables to the serial RJ-45 port (CON) on the Cisco embedded ASR1000-RP1 (see “Common
Connectors for Cisco ASR 1001 Route Processor” in the Cisco ASR 1001 Router Faceplate Common Components
section).
Step 2
Run the cable up and through the cable-management bracket and connect the other end of the RJ-45 cable to the RJ-45
adapter (see “Cisco ASR 1001 Router AC Power Supply and DC Power Supply” figure in the Cisco ASR 1001 Router
Power Supply Installation section).
Step 3
Connect the adapter to your video terminal to complete the cable connection.
Step 4
Power on your video terminal.
Step 5
Configure your video terminal to match the following default console port settings:
•
9600 baud
•
8 data bits
•
No parity generation or checking
•
1 stop bit
•
No flow control
Step 6
Go to the Connecting Cables, on page 443 to continue the installation.
Connecting Cables
Keep the following guidelines in mind when connecting external cables to the Cisco ASR 1001 Router:
•
To reduce the chance of interference, avoid crossing high-power lines with any interface cables.
•
Verify all cabling limitations (particularly distance) before powering on the system.
Cisco ASR 1000 Series Router Hardware Installation Guide
443
Cisco ASR 1001 Router Overview and Installation
Connecting Cables
