Cisco ASR1000-ESP for the Cisco ASR 1001 Router Description
The Cisco ASR 1001 Router supports the Cisco ASR1000-ESP2.5 and Cisco ASR1000-ESP5 (with license)
embedded services processors.
Table 84: Cisco ASR 1001 LEDs, on page 422 describes the Cisco ASR 1001 LEDs.
Table 84: Cisco ASR 1001 LEDs
Behavior DescriptionColorLEDLED LabelNo.
All power supplies are
within operational limits.
Solid greenPowerPWR1
Off. The router is in
standby mode.
Off
The embedded services
processor is green when
active.
GreenActiveACTV2
Code has downloaded
successfully and is
operational.
GreenSTATUSSTAT3
BOOT ROM has loaded
successfully.
Yellow
Not booted.Red
Will always be off.NoneStandbySTBY4
You can upgrade the throughput of the ESP from 2.5 Gbps to 5 Gbps by applying a software-activated
performance upgrade license and then reloading the router. If you want to determine the current throughput
level of the ESP, run the show platform hardware throughput level command. The following example
shows the output of this command before the performance upgrade license is applied:
Router# show platform hardware throughput level
The current throughput level is 2500000 kb/s
The following example shows the output of this command after the performance upgrade license is applied:
Router# show platform hardware throughput level
The current throughput level is 5000000 kb/s
For more information about the software-activated performance upgrade license, see the Cisco ASR 1000
Series Aggregation Services Routers Release Notes at the following location:
http://www.cisco.com/en/US/docs/routers/asr1000/release/notes/asr1k_rn_rel_notes.html
Cisco ASR 1000 Series Router Hardware Installation Guide
422
Cisco ASR 1001 Router Overview and Installation
Cisco ASR 1001 Router Components
