Cisco ASR 1004 Hardware Installation Guide

DescriptionDirectionSignalPin
Receive DataInputRXD6
unusedInputDSR7
Clear to Send (tied to pin
1, RTS)
InputCTS8
Auxiliary Port Signals and Pinouts
The following table lists the pinouts of the dual RJ-45 ports for the auxiliary port.
Table 130: Auxiliary Port Pinouts for Cisco ASR1000-RP1
DescriptionDirectionSignalPin
Request to SendOutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
Ring Indicator
—
RI4
——
GND5
Receive DataInputRXD6
Data Set Ready/Data
Carrier Detect
InputDSR/DCD7
Clear to SendInputCTS8
Cisco ASR1000-RP2 Pinout Specifications
The following tables list the pinouts for the ports on the Cisco ASR1000-RP2.
MGMT Ethernet Port Pinouts
The following table lists the RJ-45 port pinouts for the front panel Management Ethernet 10/100/1000 RJ-45
port.
Cisco ASR 1000 Series Router Hardware Installation Guide
639
Cisco ASR 1000 Series Router Route Processor and Embedded Services Processor Signals and Pinouts
Auxiliary Port Signals and Pinouts

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
